American DJ NET 4 DMX Over Ethernet Node (4-Port)
American DJ Net 4 Overview
Experience a new level of dynamic lighting setups with the NET 4 DMX Over Ethernet Node from American DJ. The NET 4 supports all the industry-standard protocols, including Art-Net, sACN, DMX, and RDM to expand your integration possibilities. The four 5-pin XLR ports can be configured as inputs or outputs. The NET 4's intuitive interface features a 1.7" LCD for onboard adjustments, but control is also possible from a web browser. Highly versatile to suit various applications, power options include traditional AC input or Power over Ethernet (PoE). The unit uses M10 and M12 threads that make it easy to mount safely on a truss, but it can also be rack-mounted using an optional Aria X2 shelf.
- Choose between DHCP or static IP address settings
- Two RJ45 input and output
- Four 5-pin XLR inputs/outputs
- Compact and lightweight design
- CE and FCC certified
- IP20 rated
- Includes locking power cord
Items Included
- American DJ NET 4 DMX Over Ethernet Node (4-Port)
- Locking Power Cord
- Limited 2-Year Manufacturer Warranty
Additional Resources
American DJ Net 4 Specs
| Inputs/Outputs |
2x RJ45 Female Input/Output
4x XLR 5-Pin (DMX) Female Output 1x (Power) powerCON Input 1x (Power) powerCON Output |
| Power Source |
AC Power
|
| Protocol |
ArtNet, DMX512, RDM, sACN
|
| Inputs/Outputs |
2x RJ45 Female Input/Output
4x XLR 5-Pin (DMX) Female Output 1x (Power) powerCON Input 1x (Power) powerCON Output |
| Dimming |
Optional
|
| Power Source |
AC Power
|
| Power Consumption |
4 W
|
| Input Power |
95 to 240 VAC, 50 / 60 Hz
|
| PoE Port Power |
Yes
|
| Protocol |
ArtNet, DMX512, RDM, sACN
|
| Operating Temperature |
-4 to 113°F / -20 to 45°C
|
| Operating Humidity |
75%
|
| Storage Temperature |
77°F / 25°C
|
| Certifications |
CE, cETLus, FCC
|
| Environmental Resistance |
Dust-Resistant (IP20)
|
| Dimensions |
8.5 x 5.9 x 1.7" / 215.4 x 150.6 x 42.2 mm
|
| Weight |
3.16 lb / 1.43 kg
|
| Package Weight |
3.885 lb
|
| Box Dimensions (LxWxH) |
11.2 x 8.7 x 4.2"
|
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
