ASUS Pro WS B850M-ACE SE AM5 mATX Motherboard
HomeStore

ASUS Pro WS B850M-ACE SE AM5 mATX Motherboard

ASUS Pro WS B850M-ACE SE AM5 mATX Motherboard

ASUS WS B850M-ACE SE Specs

Key Specs
Chipset
AMD B850
CPU Socket
AM5
Memory Slots
4x 288-Pin
Memory Support
DDR5 8000, 8200, 8266, 8400, 8600, 8666, 8800, 8933, 9066 MT/s
Storage Slots
2x M.2 (M Key) 2280 (PCIe 5.0 x4)
Expansion Slots
1x PCIe 5.0 x16
Wi-Fi
No
Form Factor
Micro-ATX
CPU
Chipset
AMD B850
CPU Socket
AM5
Back Panel I/O
USB
2x USB-C (USB 3.1/3.2 Gen 2)
3x USB-A (USB 3.1/3.2 Gen 2)
2x USB-A (USB 2.0)
Thunderbolt
No
Display
1x HDMI
1x DisplayPort
1x VGA
Audio
2x 1/8" / 3.5 mm
Ethernet / Controller
1x Realtek 10GbE
1x Intel 2.5Gigabit
1x Intel Gigabit
Buttons
Clear CMOS
Memory
Memory Slots
4x 288-Pin
Memory Support
DDR5 8000, 8200, 8266, 8400, 8600, 8666, 8800, 8933, 9066 MT/s
Maximum Capacity
256 GB
Channel Architecture
Dual Channel
ECC Support
Non-ECC Unbuffered
Storage Expansion
SATA
4x SATA III
Storage Slots
2x M.2 (M Key) 2280 (PCIe 5.0 x4)
U.2
1
RAID Support
RAID 0, 1, 5, 10
Internal I/O
Expansion Slots
1x PCIe 5.0 x16
USB
2x USB 2.0 Header (Supports 4 USB-A Port)
1x USB 3.0 / 3.1/3.2 Gen 1 Header (Supports 2 USB-A Port)
Air Cooling
2x 4-Pin CPU
3x 4-Pin System
Liquid Cooling
1x 4-Pin Pump
Power Connectors
1x 24-Pin Mainboard
1x 4-Pin CPU
1x 8-Pin CPU
Security
Chassis Intrusion, TPM Header
Diagnostics
Flash BIOS, Reset
Add-On
1x Thunderbolt Header
BIOS
ROM
512 Mb
Audio
Audio Codec
Realtek (7.1-Channel)
DAC
No
Wireless
Wi-Fi
No
Bluetooth
No
Software
OS Compatibility
Windows 10 to 11
Physical
Form Factor
Micro-ATX
Dimensions
9.6 x 9.6" / 243.8 x 243.8 mm

Additional Resources

No additional resources available


All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
$192.15

Original: $640.49

-70%
ASUS Pro WS B850M-ACE SE AM5 mATX Motherboard—

$640.49

$192.15
