CGS - TE CONNECTIVITY SBCHE639RJ Through Hole Resistor, 39 ohm, 16.5 V, Axial Leaded, 7 W, � 5%, SBC Series
CGS - TE CONNECTIVITY SBCHE639RJ Through Hole Resistor, 39 ohm, 16.5 V, Axial Leaded, 7 W, � 5%, SBC Series
The TE Connectivity SBC (Square Ceramic) series are through hole, power wirewound resistors. These resistors are wound on continuous glass fibre elements or have a ceramic core depending on resistance value. The element is housed in a ceramic case and sealed with inorganic silica filler. Their construction gives a resistor with high insulation resistance and low surface temperature, capable of withstanding high overload currents. These resistors are ideally suited to a variety of applications within industrial and commercial environments where performance and reliability are of prime importance. The SBC series resistors are mainly used in fan force ovens, cooker hoods, power supplies and triac based speed control applications.
- Resistance value ranges from 0.2ohm to 22Kohm
- Maximum power rating of 17W
- Available in �5% and �10% tolerance
- Temperature coefficient is 200ppm/�C (400ppm/�C below 18ohm)
- Operating temperature range -55�C to +350�C
- Vertical or axial mounting style
- Fusible style, non flammable
- Special solvent resistance
Applications
Industrial, Consumer Electronics, Portable Devices, Power Management
Product details
| Temperature Coefficient | � 200ppm/�C |
| Power Rating | 7W |
| Automotive Qualification Standard | - |
| Resistance | 39ohm |
| Resistance Tolerance | � 5% |
| Resistor Element Type | Wirewound |
| Product Range | SBC Series |
| Resistor Case Style | Axial Leaded |
| Voltage Rating | 16.5V |
Other details
| Brand | CGS - TE CONNECTIVITY |
| Part Number | SBCHE639RJ |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
$0.77
Original: $2.57
-70%CGS - TE CONNECTIVITY SBCHE639RJ Through Hole Resistor, 39 ohm, 16.5 V, Axial Leaded, 7 W, � 5%, SBC Series—
$2.57
$0.77CGS - TE CONNECTIVITY SBCHE639RJ Through Hole Resistor, 39 ohm, 16.5 V, Axial Leaded, 7 W, � 5%, SBC Series
The TE Connectivity SBC (Square Ceramic) series are through hole, power wirewound resistors. These resistors are wound on continuous glass fibre elements or have a ceramic core depending on resistance value. The element is housed in a ceramic case and sealed with inorganic silica filler. Their construction gives a resistor with high insulation resistance and low surface temperature, capable of withstanding high overload currents. These resistors are ideally suited to a variety of applications within industrial and commercial environments where performance and reliability are of prime importance. The SBC series resistors are mainly used in fan force ovens, cooker hoods, power supplies and triac based speed control applications.
- Resistance value ranges from 0.2ohm to 22Kohm
- Maximum power rating of 17W
- Available in �5% and �10% tolerance
- Temperature coefficient is 200ppm/�C (400ppm/�C below 18ohm)
- Operating temperature range -55�C to +350�C
- Vertical or axial mounting style
- Fusible style, non flammable
- Special solvent resistance
Applications
Industrial, Consumer Electronics, Portable Devices, Power Management
Product details
| Temperature Coefficient | � 200ppm/�C |
| Power Rating | 7W |
| Automotive Qualification Standard | - |
| Resistance | 39ohm |
| Resistance Tolerance | � 5% |
| Resistor Element Type | Wirewound |
| Product Range | SBC Series |
| Resistor Case Style | Axial Leaded |
| Voltage Rating | 16.5V |
Other details
| Brand | CGS - TE CONNECTIVITY |
| Part Number | SBCHE639RJ |
| Quantity | Each |
| Technical Data Sheet EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
