CHAUVET DJ Swarm Wash FX ILS Derby, Wash, Laser, Strobe, Multi-Effects Fixture
CHAUVET DJ Swarm Wash FX ILS Overview
Lighting designers and mobile entertainers looking to thrill their audience should check out the CHAUVET DJ Swarm Wash FX ILS, a multi-effects light that combines an RGBAW (red, green, blue, amber, and white) LED rotating derby effect with an RGB+UV (red, green, blue + ultraviolet) LED wash light, green/red laser diodes, and a white SMD LED strobe, in a single compact fixture. The Integrated Lighting System (ILS) is a complete lighting ecosystem technology that provides an advanced, coordinated light show across multiple fixture types, allowing any ILS-enabled fixer to be controlled wired or wirelessly.
The effects can be coordinated to create instant light shows with countless multicolor LED beams, UV-infused color washes, eye-catching strobe effects and chases, and hundreds of red and green beams that can both rotate and strobe. The fixture provides wide coverage angles of 82° for the laser, 65° for the derby, 71° for the strobe, and 46° for the washes�suitable for blanketing a stage or dancefloor. The Swarm Wash FX ILS allows for both standalone and DMX operation. For use without a DMX controller, you can choose between sound-active or automatic modes. The Master/Slave option lets you coordinate multiple fixtures without the need for a controller. The fixture is equipped with a universal, autosensing power supply and is compatible with the IRC-6 wireless remote (available separately).
- 4-in-1 light using LEDs that combines an RGBAW rotating derby, RGB+UV wash, red/green laser, and a ring of white SMD strobes
- Integrated Lighting System (ILS) is a complete lighting ecosystem technology that provides an advanced coordinated light show across multiple fixture types
- D-Fi USB compatibility for wireless Master/Slave, or DMX control
- Access built-in automated programs via IRC6 remote, Master/Slave, or DMX
- Red and green laser beams project thousands of beams for maximum coverage
- Generate complex looks easily with built-in eye-catching automatic and sound-activated programs
- Save time running extension cords by power linking multiple units
- Fits best inside the CHS-40 VIP gear bag
In the Box
- CHAUVET DJ Swarm Wash FX ILS Derby, Wash, Laser, Strobe, Multi-Effects Fixture
- Power Cord
- Mounting Hardware
CHAUVET DJ Swarm Wash FX ILS Specs
| Fixture Type | Special Design |
| Light Source | Effect Light: 5 x Color LED - 2 W / 650 mA Wash: 8 x Color/UV LED - 1.5 W / 600 mA Strobe: 12 x White LED (SMD) - 1 W / 300 mA |
| Light Source Life Expectancy | 50,000 Hours |
| Colors | Effect Light: Red Green Blue Amber White Wash: Red Green Blue Ultraviolet Strobe: White |
| Laser | 1 x Red: 650 nm / 100 mW 1 x Green: 520 nm / 30 mW Laser Class: 3R, 3B |
| Coverage Angle | Laser: 82° Effect Light: 65° Strobe: 71° Wash: 46° |
| Shutter / Strobe | Electronic |
| Dimming | 0 to 100% |
| Operating Modes | Automatic, DMX, Primary/Secondary, Sound-Active, Standalone |
| Macros / Programs | Sound-Active |
| Effects | Blinder (Variable Speed) |
| Strobe Rate | 0 to 20 Hz |
| Gobos | None |
| Control Protocols | DMX512 |
| DMX Channel Modes | 2 Mode(s): 2 / 18-Channel |
| Display / Controls | LED / 4-Button |
| Remote Control | IR Remote (with Optional Equipment) |
| Inputs/Outputs | 1 x XLR 3-Pin DMX Input 1 x XLR 3-Pin DMX Output |
| AC Input Power | 100 to 240 VAC, 50/60 Hz |
| AC Power Connector | Input: 1 x IEC Output: 1 x Edison |
| Power / Current Consumption | 120 VAC, 60 Hz: 51 W / 0.7 A 230 VAC, 50 Hz: 50 W / 0.4 A |
| Power Linking | 11 Units at 120 VAC 20 Units at 230 VAC Total Current: 8 A |
| IP Rating | None |
| Mounting | Mounting Bracket, Single Yoke Only |
| Included Accessories | 1 x Power Cable |
| Exterior Color | Black |
| Max Housing Temperature | 95°F / 35°C |
| Cooling | Convection |
| Certifications | CE *as per Manufacturer |
| Dimensions | 13.1 x 13 x 9.4" / 33.3 x 33 x 23.9 cm |
| Weight | 9.5 lb / 4.3 kg |
| Package Weight | 11.6 lb |
| Box Dimensions (LxWxH) | 14.9 x 14.4 x 12.4" |
CHAUVET DJ Swarm Wash FX ILS Reviews
