Coilcraft POE70P-50LB POE70P-50LB Smps Transformer Flyback 1.4 A 250kHz 7 W 1.5 kV

The POE70P-50LB is a Flyback Transformer with ferrite core and tin-silver-copper over tin over nickel over phosphor bronze terminations. This transformer is developed for Powered Devices (PD) in IEEE 802.3af compliant PoE (3, 7 and 13W) applications.

• Designed to operate in continuous mode at 250kHz with an input of 36 to 72VDC
• 1500Vrms (1 minute) isolation from primary and bias to secondary
• 500Vrms (1 minute) isolation between all other windings
• 250kHz Switching frequency
• 12V, 20mA Bias winding output

Applications

Communications & Networking, Industrial

Other details

Brand	COILCRAFT
Part Number	POE70P-50LB
Quantity	Each (Supplied on Cut Tape)
Technical Data Sheet EN
