COSEL MGFS404812 Isolated Through Hole DC/DC Converter, ITE, DIP, 4:1, 40.8 W, 1 Output, 12 V
COSEL MGFS404812 Isolated Through Hole DC/DC Converter, ITE, DIP, 4:1, 40.8 W, 1 Output, 12 V
Product Overview
MGFS404812 is a MGFS40 series PCB mount DC-DC converter in an industry standard 1" X 1" package. It features include built-in overcurrent protection circuits (recovers automatically), built-in remote ON/OFF and a six-sided shield.
- Input voltage range from 18V to 76V
- Output power of 40.8W
- Output voltage of 12V, output current of 3.4A
- I/O isolation voltage DC1,500V (1 minute)
- High efficiency by synchronized rectification circuit
- Output voltage adjustability by external variable resistor
- High reliability : not built-in aluminium and tantalum electrolytic capacitor
- Operating temperature/humidity of -40 to +85?, 20 to 95%RH (non condensing) (required derating)
- UL62368-11, C-UL, EN62368-1 safety approvals
- 25.4 x 9.9 x 25.4mm (W x H x D) case size
Product details
Other details
| Brand | COSEL |
| Part Number | MGFS404812 |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
Original: $83.73
-70%$83.73
$25.12COSEL MGFS404812 Isolated Through Hole DC/DC Converter, ITE, DIP, 4:1, 40.8 W, 1 Output, 12 V
Product Overview
MGFS404812 is a MGFS40 series PCB mount DC-DC converter in an industry standard 1" X 1" package. It features include built-in overcurrent protection circuits (recovers automatically), built-in remote ON/OFF and a six-sided shield.
- Input voltage range from 18V to 76V
- Output power of 40.8W
- Output voltage of 12V, output current of 3.4A
- I/O isolation voltage DC1,500V (1 minute)
- High efficiency by synchronized rectification circuit
- Output voltage adjustability by external variable resistor
- High reliability : not built-in aluminium and tantalum electrolytic capacitor
- Operating temperature/humidity of -40 to +85?, 20 to 95%RH (non condensing) (required derating)
- UL62368-11, C-UL, EN62368-1 safety approvals
- 25.4 x 9.9 x 25.4mm (W x H x D) case size
Product details
Other details
| Brand | COSEL |
| Part Number | MGFS404812 |
| Quantity | Each |
| Technical Data Sheet EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
