CRYDOM D1D60 Solid State Relay, SPST-NO, 60 A, 100 VDC, Panel, Screw, DC Switch
The D1D60 is a panel-mount Solid State Relay with screw terminals and aluminum baseplate. The 1-DC series DC output solid state relay features redesigned housing with anti-rotation barriers and improved SEMS screw and washer.
- MOSFET output
- Epoxy-free design
- UL94V-0 Flame-rated housing
- 0.1mA Maximum off-state leakage current at rated voltage
- 5mA Minimum load current
- 0.6VDC Maximum on-state voltage drop at rated current
- 0.34°C/W Thermal resistance junction to case
- 1°C/W Minimum heat sink for rated current at 40°C
- 1000Hz Maximum pulse wide modulation frequency
- 3.5VDC Minimum turn-on voltage
- 1VDC Minimum turn-off voltage
- 3750VRMS Dielectric strength (input/output/base (50/60Hz))
- 8pF Maximum capacitance (input/output)
Applications
Industrial
Warnings
Disconnect all power before installing or working with this equipment. Risk of material damage and hot enclosure.
Product details
| Relay Mounting | Panel |
| Control Voltage Max | 32VDC |
| Load Current | 60A |
| Control Voltage Min | 3.5VDC |
| Product Range | 1-DC Series |
| Relay Terminals | Screw |
| Operating Voltage Min | 0VDC |
| Switching Mode | DC Switch |
| Contact Configuration | SPST-NO |
| Operating Voltage Max | 100VDC |
Other details
| Brand | CRYDOM |
| Part Number | D1D60 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Drawing EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
$58.89
