EPCOS B72214S0141K101 TVS Varistor, 140 V, 180 V, B722 Series, 360 V, Disc 14mm, Metal Oxide Varistor (MOV)
EPCOS B72214S0141K101 TVS Varistor, 140 V, 180 V, B722 Series, 360 V, Disc 14mm, Metal Oxide Varistor (MOV)
Product details
| Operating Temperature Min | -40°C |
| Clamping Voltage Vc Max | 360V |
| Peak Surge Current @ 8/20µs | 4.5kA |
| Voltage Rating V DC | 180V |
| Operating Temperature Max | 85°C |
| Varistor Case Style | Disc 14mm |
| Product Range | B722 Series |
| Automotive Qualification Standard | - |
| Varistor Type | Metal Oxide Varistor (MOV) |
| Peak Energy (10/1000uS) | 36J |
| Voltage Rating V AC | 140V |
Other details
| Brand | EPCOS |
| Part Number | B72214S0141K101 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Product Change Notice EN | |
