Harwin G125-FC11605F1-0450L Cable Assembly Wire to Board 16 Position Receptacle Free End 17.7 " 450 mm White
Harwin G125-FC11605F1-0450L Cable Assembly Wire to Board 16 Position Receptacle Free End 17.7 " 450 mm White
Harwin's Gecko Screw-Lok (G125 series) connectors provide a low profile, dual row interconnect solution, ideally suited for stacking and cable mating in areas where PCB real estate is at a premium. With space and weight a consideration for many high-reliability applications, G125 connectors are designed to offer high performance in a miniature package. Improving on the popular 2mm pitch Datamate series, and harnessing the modern technology of micro-machining, this range brings the best of the high-reliability specifications to a smaller size. Still capable of 2A per contact, Gecko gives both significant weight and space-saving advantages over Micro-D connections
- With floating hex socket head fixings
- 2A per contact (all electrically loaded; 2.8A per individual contact)
- 4-finger Patented* contact design to maintain electrical contact through high vibration and shock
- Improved operating temperature range: -65°C to +150°C
- 1,000 Mating cycles durability
- Low outgassing properties - 0.68% TML, 0.01% CVCM, 0.26 WVR (Water Vapour Recovered)
- Keyway Polarisation Points - 3 polarising points on each component prevent mis-mating
- No. 1 Position identified, Potting Wall Housings are clearly marked with identifier for fast visual inspection
- Cable connectors feature a rear potting wall adding an extra level of strain relief
Agriculture, Automation & Process Control, Automotive, Avionics, Industrial, Renewable Energy, Robotics, Telecommunications
Product details
| Connector Type A | Wire to Board 16 Position Receptacle |
| Connector Type B | Free End |
| Cable Length - Imperial | 17.7" |
| Cable Length - Metric | 450mm |
| Jacket Colour | White |
| Product Range | Gecko SL G125 Series |
Other details
| Brand | HARWIN |
| Part Number | G125-FC11605F1-0450L |
| Quantity | Each |
| Enhanced Product Overview EN |  |
| Drawing EN | |
| Manufacturer Catalogue EN | |
| One Page Summary EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
