MEAN WELL DDRH-30-24P Isolated Through Hole DC/DC Converter, PCB Mount, ITE & Industrial, DIP, 10:1, 30 W, 1 Output, 24 V
MEAN WELL DDRH-30-24P Isolated Through Hole DC/DC Converter, PCB Mount, ITE & Industrial, DIP, 10:1, 30 W, 1 Output, 24 V
Product Overview
DDRH-30-24P is a DDRH-30 series 150 to 1500VDC, high reliable, ultra-high input, DC-DC converter which can supply stable working voltage for the load. Main features are compact size, wide range operating temperature, low ripple and noise, complete protections and so on. DDRH-30 is designed to meet UL 1741 (by requested) and IEC62109-1 standard. Protections includes short circuit, overload, over voltage, DC input under voltage, DC input reverse polarity. It is suitable for industrial automation, surveillance, telecommunication and can be widely deployed in the applications of new energy generation such as solar power, and windmill power generation, for instances, photovoltaic power systems, high voltage inverting, DC bus centralized application, ESS, charging pile, railway and so forth.
- 10:1 ultra-wide input range
- 4KVAC 1/0 high isolation (reinforced isolation)
- Fanless design, fully encapsulated, cooling by free air convection
- Ultra-wide operating temperature range from -40 to +80°C ( <gt/> +50°C derating)
- Operating altitude up to 5000meters
- 3 years warranty, dimension (L x W x H) is 89 x 63.5 x 25mm
- 30W rated wattage
- 24V output voltage
- PCB mounting type
Product details
Other details
| Brand | MEAN WELL |
| Part Number | DDRH-30-24P |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
Original: $59.60
-70%$59.60
$17.88MEAN WELL DDRH-30-24P Isolated Through Hole DC/DC Converter, PCB Mount, ITE & Industrial, DIP, 10:1, 30 W, 1 Output, 24 V
