MEAN WELL MDS02M-03N Isolated Through Hole DC/DC Converter, ITE, Industrial & Medical, SIP, 2 W, 1 Output, 3.3 V

MEAN WELL MDS02M-03N Isolated Through Hole DC/DC Converter, ITE, Industrial & Medical, SIP, 2 W, 1 Output, 3.3 V

MEAN WELL MDS02M-03N Isolated Through Hole DC/DC Converter, ITE, Industrial & Medical, SIP, 2 W, 1 Output, 3.3 V

Product Overview

MDS02M-03N is a MDS02- N (New) series 2W isolated and unregulated module type medical grade DC- DC converter with SIP-7 package. Suitable for medical devices, medical oxygen monitor, CT scanning, medical carts, oral care equipment, telecom/ datacom system, wireless network, industrial control facility.

Input voltage range from 10.8 to 13.2V DC
Single output voltage of 3.3V
Comply with IEC/UL2368-1 and LVD IEC60601-1
Medical safety approved (1xMOPP/2xMOOP) according to IEC60601-1
Low patient leakage current <2µA
Protection: short circuit(continuous)
6KV DC high I/O isolation (reinforced insulation)
Low cost
3 years warranty
Operating temperature range from -40 to 95°C

Product details

Technical Specifications

Power Supply Applications

ITE, Industrial & Medical

Input Ratio

-

No. of Outputs

1 Output

Output Current - Output 1

606mA

Output Current - Output 2

-

Isolation Voltage

6kV

DC / DC Converter Output Type

Fixed

Height

11.5mm

Input Voltage DC Min

10.8V

Product Range

MDS02-N Series

DC / DC Converter Type

SIP

Output Power Max

2W

Output Voltage - Output 1

3.3V

Output Voltage - Output 2

-

Output Regulation

Unregulated

Input Voltage DC Nom

12V

Width

7.1mm

Depth

19.7mm

Input Voltage DC Max

13.2V

SVHC

No SVHC (21-Jan-2025)

Other details

Brand	MEAN WELL
Part Number	MDS02M-03N
Quantity	Each
Technical Data Sheet EN

All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.

$2.81

Original: $9.38

-70%
