Multicomp PRO MP007727 MP007727 LED Driver IP20 Lighting 60 W 24 V 2.5 A Constant Voltage 200

These Multicomp Pro TRIAC P Dimmable LED Drivers dim via leading and trailing edge technology. The series is available in both Constant voltage and constant current. The series starts at 30W, 60W, 100W, 150W 200W, 300W and 360W power options with all options available in 12V and 24V voltage outputs. Thats series is the optimal LED driver for all high power LED applications.

• 60W, 24V, IP20 triac dimmable LED driver
• Constant voltage/ PWM output
• Leading & trailing edge dimmable
• AC input range 200VAC to 240VAC
• Built-in active PFC function
• Efficiency up to 85%
• Short circuit/ over loading/ over current/ over temperature protections
• Full protection plastic housing easy installation
• Cooling by free air convection
• Suitable for LED lighting and moving signs

• 3 years warranty
• Working Temperature: -40°C to +70°C

Applications

LED Lighting, Power Supplies, Electrical, Installations

Footnotes Safety Standards: EN61347-1, EN61347-2-13; EMC Emission Compliance to EN55015, EN61000-3-2,3 (greater-than 60%load)

Other details

Brand	MULTICOMP PRO
Part Number	MP007727
Quantity	Each
Technical Data Sheet EN
