MURATA POWER SOLUTIONS CME0305S3C Isolated Board Mount DC/DC Converter, 1 Output, 750 mW, 5 V, 150 mA
MURATA POWER SOLUTIONS CME0305S3C Isolated Board Mount DC/DC Converter, 1 Output, 750 mW, 5 V, 150 mA
Product details
| No. of Outputs | 1 Output |
| Output Power Max | 750mW |
| Output Voltage - Output 1 | 5V |
| Output Current - Output 1 | 150mA |
| Output Voltage - Output 2 | - |
| Output Current - Output 2 | - |
| Output Voltage - Output 3 | - |
| Output Current - Output 3 | - |
| Product Range | CME Series |
| Input Voltage DC Min | 2.97V |
| Input Voltage DC Max | 3.63V |
| DC / DC Converter Output Type | Fixed |
| DC / DC Converter Type | SIP |
| DC / DC Converter Mounting | Through Hole |
| Approvals & Standards | - |
| Width | 6mm |
| Height | 7.46mm |
| Depth | 11.48mm |
Other details
| Brand | MURATA POWER SOLUTIONS |
| Part Number | CME0305S3C |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Product Change Notice EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
