NI / EMERSON 789887-01 Multifunction I/O Device, USB-6421, 250 kSPS, 16 bit, 16 Input, 2 Output, 16 Input/Output
NI / EMERSON 789887-01 Multifunction I/O Device, USB-6421, 250 kSPS, 16 bit, 16 Input, 2 Output, 16 Input/Output
Product Overview
789887-01 is a 16bit, 250ks/s (16AI, 2 AO, 16 DIO) mioDAQ, USB-6421 multifunction I/O device. The USB-6421 is a USB type-C bus powered mioDAQ device with analogue I/O, digital I/O and four counters. It features analogue input channels with four input range settings from ±200mV to ±10V and analogue output channels that can output ±10V with update rates of 250ks/s/ch. Additionally, the USB-6421 digital I/O channels can function as static input or output channels, hardware-timed channels up to 10MHz, or as triggers, clocks or I/O for the four onboard counters. The USB-6421 also supports FLexLogger Lite, free data acquisition software from NI and includes documented APIs and examples for LabView, Python, C/C++ and more.
- Bus-powered USB Type-C connection
- Engineers use mioDAQ to take ±10V measurements and build electromechanical test systems
- 2x 36-position spring terminals
- 2.61mV analogue input absolute accuracy
- Dimension is 116.7mm x 177.0mm x 30.4mm
Contents
NI mioDAQ model USB-6421, One 2 m USB-C to USB-C cable with locking screw, Spring terminals with back shells for strain relief, NI screwdriver.
Product details
Other details
| Brand | NI / EMERSON |
| Part Number | 789887-01 |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
Original: $2,144.64
-70%$2,144.64
$643.39NI / EMERSON 789887-01 Multifunction I/O Device, USB-6421, 250 kSPS, 16 bit, 16 Input, 2 Output, 16 Input/Output
