Omron Industrial Automation G2R-2-SNI AC230(S) General Purpose Relay G2RS Series Power Non Latching Dpdt 230 VAC 5 A

The Omron G2RS series are industrial plug-in relays. These electromechanical power relays are slimline, space saving relays with enhanced features mainly used for general purpose applications.

• Space saving 16mm with socket
• SPDT, DPDT contact configurations
• LED indicator, colour coded green for DC versions, red for AC versions
• Test button, momentary and lockable, blue for DC, red for AC versions
• Screwless clamp terminal sockets available
• Built-in mechanical operation indicator
• Selectable coil voltage of 6VDC, 12VDC, 24VDC, 48VDC, 24VAC, 110VAC, 120VAC, 230VAC, 240VAC
• Maximum switching capacity of 10A, 8A at 250VAC and 30VDC

Applications

Industrial, Power Management, Automation & Process Control

Other details

Brand	OMRON INDUSTRIAL AUTOMATION
Part Number	G2R-2-SNI AC230(S)
Quantity	Each
Technical Data Sheet EN
Certificate of Conformity EN
