PANASONIC EEEFK1E102AQ SMD Aluminium Electrolytic Capacitor, Radial Can - SMD, 1000 µF, 25 V, 5000 hours @ 105°C, Polar
PANASONIC EEEFK1E102AQ SMD Aluminium Electrolytic Capacitor, Radial Can - SMD, 1000 µF, 25 V, 5000 hours @ 105°C, Polar
The EEEFK1E102AQ is a surface-mount medium-size aluminium Electrolytic Capacitor features high reliability, long life, low impedance and high ripple current of the top-class in AL-E. The FK-V series aluminium electrolytic capacitor is applied to an in-vehicle electric equipment and the anti-vibration type (more than �8mm) can support.
- Sheathless (metal case) appearance
Product details
| Capacitor Case / Package: Radial Can - SMD |
| Capacitance: 1000µF |
| Voltage(DC): 25V |
| ESR: - |
| Lifetime @ Temperature: 5000 hours @ 105°C |
| Polarity: Polar |
| Product Range: FK |
| Capacitance Tolerance: ± 20% |
| Capacitor Terminals: Solder |
| Product Diameter: 12.5mm |
| Product Length: - |
| Product Width: - |
| Product Height: 13.5mm |
| Ripple Current: 1.1A |
| Operating Temperature Min: -55°C |
| Operating Temperature Max: 105°C |
| Qualification: AEC-Q200 |
| MSL: - |
Other details
| Brand | PANASONIC |
| Part Number | EEEFK1E102AQ |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
