PANASONIC EEEFN1V471UP SMD Aluminium Electrolytic Capacitor, Radial Can - SMD, 470 µF, 35 V, 0.08 ohm
PANASONIC EEEFN1V471UP SMD Aluminium Electrolytic Capacitor, Radial Can - SMD, 470 µF, 35 V, 0.08 ohm
- FN series V type high temperature lead-free reflow SMD aluminium electrolytic capacitor
- Compact and low ESR capacitor
- Automotive grade AEC-Q200 complaint
Product details
| Capacitor Case / Package: Radial Can - SMD |
| Capacitance: 470µF |
| Voltage(DC): 35V |
| ESR: 0.08ohm |
| Lifetime @ Temperature: 2000 hours @ 105°C |
| Polarity: Polar |
| Product Range: FN |
| Capacitance Tolerance: ± 20% |
| Capacitor Terminals: Solder |
| Product Diameter: 10mm |
| Product Length: - |
| Product Width: - |
| Product Height: 10.2mm |
| Ripple Current: 850mA |
| Operating Temperature Min: -55°C |
| Operating Temperature Max: 105°C |
| Qualification: AEC-Q200 |
Other details
| Brand | PANASONIC |
| Part Number | EEEFN1V471UP |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
