PANASONIC ELECTRONIC COMPONENTS ERZV10D271 TVS Varistor, 175 V, 225 V, ZNR V Series, 455 V, Disc 10mm, High Surge Current
PANASONIC ELECTRONIC COMPONENTS ERZV10D271 TVS Varistor, 175 V, 225 V, ZNR V Series, 455 V, Disc 10mm, High Surge Current
Product details
| Voltage Rating V AC | 175V |
| Voltage Rating V DC | 225V |
| Product Range | ZNR V Series |
| Clamping Voltage Vc Max | 455V |
| Varistor Case Style | Disc 10mm |
| Varistor Type | High Surge Current |
| Peak Surge Current @ 8/20µs | 3.5kA |
| Operating Temperature Min | -40°C |
| Operating Temperature Max | 85°C |
| Peak Energy (10/1000uS) | 49J |
| Automotive Qualification Standard | - |
Other details
| Brand | PANASONIC ELECTRONIC COMPONENTS |
| Part Number | ERZV10D271 |
| Quantity | Each |
| Technical Data Sheet EN |  |
