Texas Instruments TS3USB30ERSWR Analogue Switch 2 Channels 10 ohm 3V to 4.3V QFN Pins
The TS3USB30ERSWR is a high-bandwidth 1:2 Analog Switch specially designed for the switching of high-speed USB 2.0 signals in handset with limited USB I/Os. The wide bandwidth (900MHz) of this switch allows signals to pass with minimum edge and phase distortion. The device multiplexes differential outputs from an USB host device to one of two corresponding outputs, or from two different hosts to one corresponding output. The switch is bidirectional and offers little or no attenuation of the high-speed signals at the outputs. It is designed for low bit-to-bit skew and high channel-to-channel noise isolation and is compatible with various standards, such as high-speed USB 2.0 (480Mbps). The TS3USB30E integrates ESD protection cells on all pins.
- IOFF Supports partial power-down-mode operation
- Low power consumption
- Latch-up performance exceeds 100 mA per JESD 78, class II
- ESD performance I/O port to GND
- Green product and no Sb/Br
Industrial, Portable Devices, Consumer Electronics
Warnings Device has limited built-in ESD protection, leads should be shorted together or the device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.Other details
| Brand | TEXAS INSTRUMENTS |
| Part Number | TS3USB30ERSWR |
| Quantity | Each (Supplied on Cut Tape) |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
$1.31
Texas Instruments TS3USB30ERSWR Analogue Switch 2 Channels 10 ohm 3V to 4.3V QFN Pins—
$1.31
Texas Instruments TS3USB30ERSWR Analogue Switch 2 Channels 10 ohm 3V to 4.3V QFN Pins
The TS3USB30ERSWR is a high-bandwidth 1:2 Analog Switch specially designed for the switching of high-speed USB 2.0 signals in handset with limited USB I/Os. The wide bandwidth (900MHz) of this switch allows signals to pass with minimum edge and phase distortion. The device multiplexes differential outputs from an USB host device to one of two corresponding outputs, or from two different hosts to one corresponding output. The switch is bidirectional and offers little or no attenuation of the high-speed signals at the outputs. It is designed for low bit-to-bit skew and high channel-to-channel noise isolation and is compatible with various standards, such as high-speed USB 2.0 (480Mbps). The TS3USB30E integrates ESD protection cells on all pins.
- IOFF Supports partial power-down-mode operation
- Low power consumption
- Latch-up performance exceeds 100 mA per JESD 78, class II
- ESD performance I/O port to GND
- Green product and no Sb/Br
Industrial, Portable Devices, Consumer Electronics
Warnings Device has limited built-in ESD protection, leads should be shorted together or the device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.Other details
| Brand | TEXAS INSTRUMENTS |
| Part Number | TS3USB30ERSWR |
| Quantity | Each (Supplied on Cut Tape) |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
