Traco Power TEP 200-7215UIR TEP 200-7215UIR Isolated Through Hole DC/DC Converter ITE & Railway 12:1 200 W 1 Output 24 V 8.4 A New
Traco Power TEP 200-7215UIR TEP 200-7215UIR Isolated Through Hole DC/DC Converter ITE & Railway 12:1 200 W 1 Output 24 V 8.4 A New
TEP 200-7215UIR is a 200W TEP 200UIR series railway-certified DC/DC converters designed for highest reliability in demanding applications. Its ultra-wide 12:1 input voltage range allows the application engineer to target an array of nominal system voltages with a single power supply design. Due to dedicated holdup capacitor connection, the TEP 200UIR meets extended holdup-time requirements without the need for bulky input capacitors. The TEP 200UIR series is EN 50155 certified for applications on rolling stock. Additional certifications include EN 61373 for mechanical shock and vibration, EN 45545-2 for fire behaviour and IEC/EN/UL 62368-1 for IT and general-purpose industrial applications.
- Input voltage range from 72(14 to 160)VDC, output voltage of 24VDC
- Maximum output current is 8400mA
- Fully encapsulated
- Typical efficiency is 89%
- Reinforced 3000VAC I/O isolation
- Remote on/off and trim function
- Protection against short-circuit (SCP), overvoltage (OVP), over temperature (OTP)
- Compact half-brick housing
- Operating temperature range from -40°C to 105°C
- 3-year product warranty
Other details
| Brand | TRACO POWER |
| Part Number | TEP 200-7215UIR |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
