Traco Power TMR 6-2412WI TMR 6-2412WI Isolated Through Hole DC/DC Converter ITE 4:1 6 W 1 Output 12 V 500 mA

The TMR 6-2412WI is an isolated 6W DC-DC Converter Module with regulated output, featuring wide 4:1 input voltage ranges. It offers 9 to 36VDC input voltage range and 12VDC output voltage. An excellent efficiency allows -40 to 71°C operation temperatures. Further features include remote ON/OFF control and continuous short circuit protection. The very compact dimensions of this converter make it an ideal solution for many space critical applications.

• Full SMD design
• Indefinite short-circuit protection
• 1500VDC I/O isolation
• 87% Typical efficiency
• 24VDC Nominal input voltage

Applications

Communications & Networking, Sensing & Instrumentation, Consumer Electronics

Other details

Brand	TRACO POWER
Part Number	TMR 6-2412WI
Quantity	Each
Technical Data Sheet EN
CAD Multiple Formats EN
