XP Power IU2424SA Isolated Through Hole DC/DC Converter Regulated ITE 2:1 2 W 1 Output 24 V 83 mA
XP Power IU2424SA Isolated Through Hole DC/DC Converter Regulated ITE 2:1 2 W 1 Output 24 V 83 mA
- Continuous short circuit protection
- 2:1 input range
- 80% efficiency
- 18-36V input voltage
- 8mA no load input current
- 24V output voltage
- 83mA output current
- 220µF maximum capacitive load
- Operating temperature is -40°C to +85°C
- 3 year warranty
Other details
| Brand | XP POWER |
| Part Number | IU2424SA |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Certificate of Conformity EN | |
| Technical Notes & Articles EN | |
